Intelligent Weighing Technology OTP-200 Thermal RS232 Line Printer

Intelligent Weighing Technology OTP-200 Thermal RS232 Line Printer: Inkless, Compliant Laboratory Data Logging System

The Intelligent Weighing Technology OTP-200 Thermal RS232 Line Printer is a highly compact, commercial-grade laboratory peripheral engineered to eliminate the operational bottlenecks of manual data recording and transcription errors in pharmaceutical, clinical, industrial, and high-precision testing labs. In tightly monitored metrology workflows, regulatory compliance mandates that all sample weight metrics feature absolute traceability. Hand-written logs introduce human margin-of-error vulnerabilities and fail to comply with strict auditing frameworks. The OTP-200 resolves this challenge by establishing a direct, electronic communication link with any RS232-capable balance, outputting pristine, tamper-proof printed metrics instantly upon sample measurement.

Engineered for seamless integration within space-restricted cleanrooms and high-throughput facility testing lines, this direct thermal printer functions entirely without ribbons, ink reservoirs, or complex toner cartridges, dramatically minimizing ongoing operational overhead. Built-in system firmware fully accommodates advanced Precisa GLP (Good Laboratory Practice) data formatting, producing cleanly structured audit trails complete with time, date, and user variables. The versatile mechanical printhead supports standard paper rolls alongside specialized, removable MAXStick® adhesive label media. This flexibility lets laboratory technicians instantly label sample vials, storage containers, or validation charts using solvent-resistant sheets that withstand common laboratory cleaning chemicals without fading or stripping.

Key Benefits:

• Inkless Direct Thermal Printing: Utilizes advanced thermal-head technology that prints directly onto heat-sensitive media rolls, completely removing the cost and mechanical downtime of changing ink ribbons.
• Precisa GLP Report Integration: Outfitted with advanced firmware optimized to interpret and structure official Good Laboratory Practice (GLP) report headers from compatible analytical balances.
• Chemical-Resistant Adhesive Media: Supports specialized OTP-200 label stock engineered to resist laboratory solvents while featuring a moderate, non-permanent adhesive that can be cleanly removed and repositioned.
• Flexible Character Configurations: Features a user-adjustable print matrix accommodating 24, 32, 42, or 48 characters per line across diverse Arial font sizes to optimize space on small data receipts.
• Tool-Free Drop-In Media Loading: Designed with an easy-access lift lid that enables laboratory staff to replace a paper or label roll in seconds, completely removing calibration delays.
• Built-In System Diagnostics: Programmed with an automated self-test routine accessible directly from the single-button interface to verify printhead clarity and print configuration parameters instantly.

Specifications:

• Brand & Manufacturer: Intelligent Weighing Technology (IWTI)
• Product Family / Name: OTP-200 Thermal RS232 Line Printer Kit
• Interface Connection Protocol: Standard Serial RS232 (Default: 9600 Baud, N, 8, 1; Adjustable from 300 to 115,200 Baud)
• Supported Balance Array: Connects with all IWTI scales, balances, and Precisa Series metrology systems
• Selectable Font Matrix: Arial 16, Arial 12, Arial 9, and Arial 8 sizes
• Nominal Print Speed: 2.0 lines per second for expedited record handoffs
• Physical Device Dimensions: 3.3” Width x 6.0” Depth x 2.2” Height (85 x 152 x 56 mm)
• Net Peripheral Weight: 0.9 lbs (400 g) ultra-lightweight workspace footprint
• Supported Media Profile: 2.25-inch (58 mm) standard thermal paper roll or MAXStick® removable label roll
• Electrical Architecture: Universal AC Adapter, 100–240 VAC, 50–60Hz with a standard US plug
• Interface Cable: 3-foot (minimum) RJ11-to-DB9F serial link cord included
• Standard Kit Inclusions: OTP-200 Printer, AC Adapter, Serial Cable, 1 x 7-Year Paper Roll, 1 x 12-Year Label Roll, Thermal Head Cleaning Pen
• Fulfillment Logistics: Direct commercial inventory distribution; facility batch orders typically process and dispatch within 24–48 hours

Includes:

• 100-240 VAC (50-60Hz) Power Suppl (US Plug)
• Serial Cable with DB9F Connector
• Roll of 2¼” (58 mm) OTP-200 Label Media
• Roll of 2¼” (58 mm) OTP-200 7 Year Paper

Extended Product Information:

• Product Brochure
